Reishi Mushroom Cultivation Container Smart Flagship

 1. Product Overview

Reishi cultivation requires high temperature, high humidity and ample diffuse light to ensure even cap colouring and active-compound accumulation. This model uses an integrated enclosure plus external equipment bay, moving refrigeration, water tanks and switchgear outside the container - freeing growing space and allowing maintenance without disturbing the internal climate.

2. Key Advantages

• Refrigeration, water tank and switchgear grouped in an external bay so the interior is fully devoted to growing

• The equipment bay opens for service without disturbing the internal climate

• Tunable blue-green spectrum ratio promoting even cap colouring and active-compound accumulation

• Optional spore-collection module that reduces spore dispersal and cross-contamination

3. Technical Specifications

项目 / Item	参数 / Specification
型号 / Model	HVC-M10E
外形尺寸 / Dimensions	12000 × 2438 × 2896 mm（40 尺标准箱）  /  12000 x 2438 x 2896 mm (40 ft ISO container)
有效栽培面积 / Effective cultivation area	50–65 m²  /  50-65 m2
层架配置 / Rack configuration	4–5 层不锈钢出菇架，配自动巡检接口  /  4-5 tier stainless racks with automatic inspection interface
温度控制范围 / Temperature range	22-30 ℃ (±0.5 ℃)  /  22-30 degC (+/-0.5 degC)
相对湿度 / Relative humidity	85-95% RH
CO₂ 浓度 / CO₂ concentration	800-1600 ppm
光照 / Lighting	0-1000 lux（可调 / adjustable）
栽培周期 / Cultivation cycle	60–90 天  /  60-90 days
装机功率 / Installed power	14–18 kW  /  14-18 kW
电源 / Power supply	380 V / 50 Hz 三相（可按目的国电压定制）  /  380 V / 50 Hz, 3-phase (customisable to destination-country voltage)
箱体传热系数 / Enclosure U-value	≤0.30 W/(m²·K)  /  <= 0.30 W/(m2.K)
控制系统 / Control system	全自动控制 + 云端数据平台 + AI 配方自学习 + 手机 APP  /  Fully automatic control with cloud data platform, self-learning AI recipes and a mobile app
主栽品种 / Primary species	灵芝（Ganoderma lucidum）  /  Reishi Mushroom (Ganoderma lucidum)



4. System Configuration

Standard configuration: Integrated external equipment bay with refrigeration unit, stainless water tank and switchgear; internal rack system; fogging humidifier; tunable-spectrum LEDs; optional spore collection module; and an intelligent control cabinet.

Enclosure and integration: 12000 x 2438 x 2896 mm (40 ft ISO container); racks: 4-5 tier stainless racks with automatic inspection interface; control: Fully automatic control with cloud data platform, self-learning AI recipes and a mobile app.

 5. Suitable Species

Primary species: Reishi Mushroom (Ganoderma lucidum). Cultivation method: bag culture requiring ample diffuse light for cap colouring. Spore collection is subject to food and pharmaceutical regulation; the specific scheme must be confirmed against destination-country rules.

 6. Application Scenarios

Standardised medicinal-mushroom cultivation bases, GAP-aligned traditional medicine projects, and health-ingredient supply chains. This is the Smart Flagship configuration; Unattended operation with full parameter traceability; suits multi-site remote management.

7. Delivery & Installation

• Factory: the enclosure, refrigeration unit, piping and electrical systems are assembled and bench-tested in our factory, followed by a 96-hour continuous operation test, with a test record supplied with the shipment.

• Transport: the enclosure matches standard ISO container dimensions and can be shipped as ordinary container cargo under FOB, CIF or DAP terms.

• On site: our engineers or authorised partners provide positioning guidance, utility connection, commissioning and operator training, normally within 5 working days.

• Deliverables: the complete unit, printed and electronic bilingual operation manuals, a PLC programme backup, crop parameter recipes, and the factory test report.

8. After-Sales Service

• Warranty: 12 months on the complete unit from acceptance, with optional extended coverage for the core refrigeration unit and control system.

• Response: repairs acknowledged within 24 hours on business days, with a solution proposed within 72 hours for critical faults.

• Remote operations: remote diagnostics, recipe and parameter upgrades, data dashboards and energy analysis (standard on the Smart Flagship configuration, optional on the others).

• Spare parts and upgrades: long-term supply of genuine parts, filters and consumables, plus control-system and technology upgrades.

• Training and cultivation support: operator, maintenance and cultivation-process training, with continuously updated crop parameter packs.
