Hollow Lettuce Floating Board Cultivation Container
Product illustration: images/vegetable/HVC-V07.jpg (Panoramic view of the floating board cultivation area)
I. Product Overview
Water spinach thrives in warm, humid conditions and grows rapidly, making it ideal for fast-turnover floating-plate hydroponic systems. The HVC-V07 model utilizes large-area floating-plate cultivation technology combined with an optimized unit designed for high-temperature operating conditions; it can be harvested within 20–30 days, providing an effective supplement during periods of summer leafy vegetable supply shortages.
II. Core Competitive Advantages
● High-temperature operation optimization: The unit is designed for operating conditions between 22–30°C, enabling stable operation even during the peak summer months.
● Fast turnover: one crop cycle every 20–30 days; annual turnover exceeds 10 cycles.
● Floating Plate Continuous Management: The entire plate can be removed and harvested as a whole, ensuring high operational efficiency.
● Heat-resistant variety compatibility: Tailored nutrient and light regimen for heat-resistant leafy vegetables.
III. Typical Technical Specifications
project | parameter |
outline dimension | 12000 × 2438 × 2896 mm (40 feet) |
Cultivation Method | Floating raft hydroponics |
Effective planting area | 85–115 m² |
growth cycle | 20–30 days |
Temperature control range | 22–30 ℃（±1 ℃） |
relative humidity | 65%–85% RH |
beam | LED 200–350 μmol/(m²·s) |
EC / pH | 1.6–2.2 mS/cm ｜ 6.0–6.5 |
installed power | 12–17 kW |
source | 380 V / 50 Hz Three-phase |
IV. System Configuration
Floating tray cultivation troughs and transplanting trays; nutrient solution circulation and filtration/disinfection system; high-temperature refrigeration unit; automatic EC/PH fertilization system; full-spectrum LED lighting; fresh air supply and internal circulation fans; intelligent control cabinet.
V. Applicable Varieties
Water spinach (Wengcai), water celery, broad-leaf lettuce, and other warm-season, fast-growing leafy vegetables.
VI.适用场景
Summer leafy vegetable supply bases; plant factories in southern China; fresh vegetable supply networks for suburban areas.
VII. Delivery and Installation
Delivered as a complete unit; commissioning shall be completed within 3 working days after on-site hoisting and power connection; guidance on ventilation and water/fertilizer management during high-temperature periods will be provided.
VIII. After-Sales Service
12-month overall warranty; specialized seasonal inspections during high-temperature periods, remote operation and maintenance services, and consumable supply.
